Max inlet gas pressure 25Mpa

Max working pressure 20Mpa

2nd stage output pressure 0.11Mpa

Working temperature -40℃~+120℃

Pressure stage number 3rd stage

Working voltage 8-16v

Working medium CNG

Max flow 24NM3/H

The implementation of standard GB/T20735-2006

Packing size 20*18*12cm

Weight 2.15kg  Engine power up to 140kW
